Live Interactive Training: Avoid Costly Panel Mistakes
You will likely encounter a panel design that calls out a “60-100A 3-phase GFCI breaker.” Then, you will discover that no manufacturer offers such a breaker in this configuration. Learn what you need to know to avoid costly panel mistakes.
Between April 1, 2024 and August 31, 2024 we have held 22 successful meetings and trained 247 Engineers from 11 MEP firms.
Meet our Presenter
Joe Cox
Engineer & Technical Director
Ground Fault Solutions
Graduated with a BSEE from Long Beach State University. Served as Director of Engineering with EOS Corporation, designing AcDc power supplies for Apple and Dell. 14 years managing technical services with Tier 1 power management semiconductor companies; Power Integrations, Infineon and Alpha Omega Semiconductor.
Here is what Engineers say about our Presentation
“Great presentation – we all really enjoy the technical ones! Thanks for presenting to the various NV5 teams too. We appreciate it.”
- Chief Electrical Engineer - Planning and Design
“Changes to NEC 210.8 B-F have challenged all of us in the industry to find new GFCI solutions. When NK Technologies reached out to us recently, we decided to invest a few hours into meeting with their application expert. Five of our electrical engineering designers attended the session and considered it time well spent. NK Technologies has an in-depth understanding of the new NEC requirements and ground fault products designed to meet them. We are thankful for their time.”
- PK Electrical
One of the top electrical and low voltage/communication design firms, In both the private and public sectors, based in Reno, NV and Denver, CO.
The Problem
The 2020 and 2023 editions of the National Electric Code (NEC) section 210.8 B through F have increased GFCI requirements in more locations than ever before. The updated code covers GFCI protection in “other than dwelling” units and focuses on GFCI protection for applicable devices powered by 3-phase power (e.g. line to line, < 250 VAC, 208 VAC typical). However, ideal GFCI solutions would also be compatible with 2-pole (e.g. line to line, 240 VAC).
These changes have an effect on Commercial and Industrial Buildings with a significant impact on Commercial Kitchens.
The Solution
Join us for a 60-minute Teams discussion addressing the market constraints on GFCI MCBs due to recent changes in the National Electric Code (NFPA 70). This session will delve into the uncertainties these changes have introduced into the MCB supply chain, particularly for devices with a 10,000+ AIC rating. Our focus will be on identifying gaps in the current GFCI MCB supply chain and presenting a universal 5 mA ground fault protection system designed for single or three-phase branch circuits up to 100 A. This innovative solution aims to effectively address the new requirements and ensure compliance, reliability, and safety in commercial and industrial buildings.
Topics Included in the Training Session:
Overview of 2023 Edition NEC Article 210.8
- New definitions added
- New Additions
Meeting the Intent of 2020 & 2023 Edition NEC, Article 90
- Why this Important
GFCI Definitions
GFCI Solutions that Meet Intent
GFCI Supply Chain Challenges
- What is available to Design In to your Projects
- Year over Year Increased demand for GFCI Devices
- GFCI MCB’s supply constrained & acerbated by incompatibility
- Overview of products available 5 maA Ground Fault Protection System
- Branch Circuit Calculations
What is a Ground Fault Relay?
Reserve a training time dedicated specifically to your organization.
Training is private and customized for you.
